SounDigital 3000.1 EVO 5 - 4Ohm

EAN: 7898644525439
SD3000.1-4 EVO5
1-channel amplifier
3000W
4 Ohm model
Small size
Read more
Description
Specifications

Description

The 3000.1EVO 5 is a compact, modern amplifier that delivers 3000W RMS of power distributed over 1 channel. The amplifier features exclusive and patented technologies that make the sound experience cleaner and more faithful, in addition to ensuring better performance and efficiency for the most daring projects.

Specifications

Power @ 4Ω: 1 X 3000W RMS

Frequency Response (-3dB):

5Hz ~ 25kHz

Subsonic Filter:

5Hz ~ 30Hz

Low Pass Filter:

50Hz ~ 1kHz

Bass Boost:

0dB ~ 12dB @ 50Hz

Operating Voltage:

8V – 16V

SNR:

92dB

Input Sensitivity:

0.2V ~ 2V

Current Draw (Music):

4Ω: 140A

Current Draw With Resistive Load:

4Ω: 280A

Total Efficiency:

4Ω: 85%

Damping Factor:

2000

Power Cable:

35mm² (2AWG)

Audio Output Cable:

4Ω: 2 x 1.5 mm² (15 AWG)

Recommended Fuse (Music):

150A

Recommended Battery:

150Ah

Width:

5.3 in / 13.6 cm

Length:

8.9 in / 22.8 cm

Height:

2.1 in / 5.48 cm

Weight:

1.75 Kg
